Brax Matrix ML10 Sub 10" Subwoofer

Description

BRAX MATRIX ML10 SUB

Precision Meets Performance

The legendary BRAX MATRIX loudspeaker series—long recognized as a benchmark in high-end automotive audio—is now expanded with the ML10 SUB. Developed and manufactured with the same uncompromising standards as all BRAX loudspeakers, the ML10 SUB sets a new benchmark in subwoofer performance.

Perfection Meets Maximum Flexibility

Thanks to its new 2 x 2 Ohm dual voice coil, the ML10 SUB offers highly flexible configuration options, allowing for clean, controlled bass reproduction with ease. The four heavy-duty terminals support three configurations:

• 1 x 4 Ohms

• 2 x 2 Ohms

• 1 x 1 Ohm

With power handling of up to 1,200 Watts, it delivers unmatched dynamic performance.

MicroSphere – The Perfect Synthesis of Weight and Stiffness

The heart of the ML10 SUB lies in its hand-scooped paper cone, enhanced by a patented MicroSphere coating. This technology embeds ceramic hollow spheres (only 75 μm in diameter) in a polymer layer applied to the cone surface.

This process delivers:

• Maximum stiffness without increasing weight

• Superior internal damping

• Improved impulse response

• Lower total Q factor compared to conventional subwoofers

Engineering Excellence with Timeless Design

Every BRAX product embodies clean, purist design and flawless craftsmanship. The ML10 SUB features:

• An extremely linear magnet drive with precision-machined pole plates

• A multi-ventilated large voice coil for superior heat management and power handling

• An aerodynamically optimized, solid aluminum die-cast basket

As with all BRAX products, the ML10 SUB comes in a luxurious wooden box with a unique serial number stored in BRAX’s official service database.

Features

• Exceptionally stiff hand-scooped paper cone with MicroSphere coating

• Special rubber surround for extended linear cone excursion

• 2 x 2 Ohms dual voice coil with long winding height for ultra-linear excursion

• Mesh-protected ventilation in T-yoke and basket for minimal compression and heat buildup

• Aerodynamically optimized and rigid die-cast aluminum basket

• Precisely engineered magnet system for optimal magnetic flux linearity

• Massive push terminals for high-current connections

Technical Specifications

Recommended Enclosure Volumes

Sealed Box

• Net Volume: 28 L

• Lower Limiting Frequency (-3 dB): 43 Hz

• DSP Highpass Filter Setting:

  • Frequency: 32 Hz

  • Characteristic: Self-defined

  • Q-Factor: 1.0

Note: Vented enclosures are not recommended for this subwoofer.

Scope of Delivery

• 1 × High-End Subwoofer BRAX MATRIX ML10 SUB

• 1 × Certificate

• 1 × Data Sheet
