Description
Eton PA1 Monoblock Channel Amplifier
Elevate your car audio with the Eton PA1, a state-of-the-art 1-channel monoblock Advanced Class-D power amplifier designed for powerful bass performance. Engineered with high-quality die-cast aluminum housing featuring a removable cover, this compact amplifier delivers up to 480W RMS at 1 ohm, ideal for subwoofer upgrades.
Key Features of the Eton PA1
- Advanced Class-D Technology: Ensures maximum efficiency and low distortion.
- High-Quality Die-Cast Aluminum Housing: Features a removable cover with integrated adjustment tool for easy tuning in confined spaces.
- Adjustable Low-Pass Filter: Slope selectable at 12 dB/oct or 24 dB/oct (25 - 250 Hz).
- Subsonic Active Filter: Fixed at 30 Hz for enhanced bass control.
- Auto-Sense On Function: Activates via SIG or DC signal.
- Variable Mounting Feet: Allows adaptation to various installation scenarios.
- Detachable Connection Plugs: Simplifies wiring for power and audio signals.
- Included Accessories: Level remote control.
Specifications Table
| Specification | Details |
|---|---|
| Amplifier Type | Monoblock (1-Channel) |
| Power Output (RMS) | 200W @ 4 Ohms, 340W @ 2 Ohms, 480W @ 1 Ohm |
| Frequency Response | Not specified (subsonic filter: 30 Hz) |
| Signal-to-Noise Ratio | 83.5 dB |
| Total Harmonic Distortion (THD+N) | < 0.02% @ 50W 60 Hz |
| Input Sensitivity | Adjustable gain: 0.45V - 6V |
| Input Impedance | High-level input: 10 Ω |
| Crossover Frequencies | Low-pass: 25 - 250 Hz (12 dB/Oct or 24 dB/Oct), Subsonic: 30 Hz |
| Damping Factor | >88 @ 4 Ω |
| Operating Voltage | Not specified |
| Idle Current | Not specified |
| Maximum Current Draw | Not specified |
| Dimensions (L x W x H) | 128 x 100 x 45 mm (5.04 x 3.94 x 1.77 inches) |
| Weight | Not specified |
| Efficiency | Not specified |
| Inputs | 4 x Audio (2 x High Level, 2 x Low Level) |
| Accessories Included | Level remote control |
