Rockford Fosgate P300X1 Punch Mono Amplifier

Rockford Fosgate P300X1 Punch Mono Amplifier

$529.00 AUD
$529.00 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.
View full details

Description

Rockford Fosgate P300X1 Punch 300 Watt Full-Range Mono Amplifier

Power up your car audio with the Rockford Fosgate P300X1, a compact, full-range Class-A/B mono amplifier delivering 300 watts RMS at 2 ohms. Perfect for driving subwoofers like the Rockford Fosgate P3SD4-12 or a center channel speaker, this Punch series amplifier fits in tight spaces. With C.L.E.A.N. setup technology and a small chassis, the P300X1 offers clean, powerful sound for factory upgrades or custom systems.

Key Features of the Rockford Fosgate P300X1

  • Class-A/B Topology: Trans•ana design ensures reliable, high-quality audio with low distortion.
  • C.L.E.A.N. Setup: Clip-limiting circuitry with LED indicators simplifies gain adjustment for distortion-free sound.
  • Compact Design: Measures 2.38" x 7.76" x 9.86" for easy installation in space-constrained vehicles.
  • Flexible Inputs: Supports RCA and high-level inputs with auto turn-on for factory head units.
  • Punch EQ2: Adjustable bass (+18dB @ 45Hz) and treble (+12.5dB @ 12kHz) for tailored sound.
  • Variable Crossovers: 12 dB/octave Butterworth high-pass and low-pass filters (50-250Hz) for precise tuning.
  • Thermal Management: Cast aluminum heatsink and Dynamic Thermal Management ensure cool operation.
  • Optional PLC2 Remote: Punch Level Control (sold separately) for on-the-fly bass adjustments.
  • CEA-2006 Compliant: Delivers real power ratings for dependable performance.
  • 1-Year Warranty: Extends to 2 years with a matching Rockford Fosgate installation kit.

Why Choose the P300X1 Amplifier?

The Rockford Fosgate P300X1 is a versatile choice for car audio enthusiasts seeking compact power and clear sound. Its 2-ohm capability drives single or multiple speakers with ease, perfect for subwoofer systems or center channels.

Specifications Table

Specification

Details

Number of Channels

Mono (1 Channel)

Power Output (RMS, 14.4V, ≤1% THD+N)

200W x 1 @ 4Ω, 300W x 1 @ 2Ω

Frequency Response

20Hz–20kHz

Total Harmonic Distortion (THD+N)

≤1.0% (at rated power, 4Ω/2Ω)

Signal-to-Noise Ratio (CEA-2006)

>85 dB (1W into 4Ω)

Input Sensitivity

Low-Level: 150mV–4V, High-Level: 450mV–12V

Crossover Controls

High-Pass: 50Hz–250Hz @ 12dB/octave Butterworth, Low-Pass: 50Hz–250Hz @ 12dB/octave Butterworth, All-Pass: Yes

Punch EQ2

Bass: 0 to +18dB @ 45Hz, Treble: 0 to +12.5dB @ 12kHz

Input Impedance

>20kΩ

Signal Input

Low-Level: 2 RCA, High-Level: 4-Pin Molex

Preamp Output

RCA Pass-Through, 4V max

Power/Ground Terminals

8-Gauge, Set-Screw

Recommended Fuse

50A (not included, in-line fuse recommended)

Circuit Topology

Full-Range Class-A/B

Efficiency

Moderate (Class-A/B design)

Heat Sink

Cast Aluminum with Dynamic Thermal Management

Visual Indicators

Power/Protect/Thermal LED, Input Clip LED, Output Clip LED (Blue: <0.5% THD, Violet: 1% THD, Red: 10%+ THD)

Remote Control

Optional PLC2 Punch Level Control

Dimensions (H x W x D)

2.38" x 7.76" x 9.86" (6.05cm x 19.71cm x 25.04cm)

Weight

10.0 lbs (4.54 kg)

Compliance

CEA-2006, CE

Warranty

1 Year (2 Years with RF Installation Kit)
