Rockford Fosgate R2-500X4 Amplifier

Overview
Primed for performance, the R2-500X4 is a 500 watt, full-range Class-D amplifier capable of operating at 4Ω or 2Ω stereo and 4Ω bridged/mono. Thanks to Class-D technology, it’s extremely efficient and reduces demand on your vehicle’s electrical system. The amp features C.L.E.A.N. circuitry for easy gain adjustment, and a P.O.W.E.R. supply that generates more power as voltage increases.

Product Overview

Rockford Fosgate’s R2 amplifiers are the foundation for great audio systems, powerful enough to drive Punch speakers and subwoofers. The latest generation has been upgraded with cutting-edge features, offering incredible value. Designed and engineered in Tempe, Arizona, these amps deliver reliable power and performance at an economical price.

R2 amplifiers are known worldwide for being underrated — consistently outperforming their specifications and producing more power than rated. The 3rd generation Prime Series amps come with the latest Rockford Fosgate technology, allowing easy setup and perfect compatibility with factory or custom aftermarket systems.

Features at a Glance

  • High Level Input Capable

  • 2/4 Channel Input Selection Switch

  • Auto-Sense Bypass Switch (for vehicles with RAP - Retained Accessory Power)

  • Balanced Differential Inputs with RCA Pass Through Outputs

  • C.L.E.A.N. Set-up for easy gain adjustment

  • Short Circuit & Over Current Protection

  • Front and Rear Variable Input Gain Controls

  • Top Mounted Control Panel

  • CEA-2006 and CE Compliant

  • Full Range Class-D Amplifier

  • Cast Aluminum Heat Sink for cooling

  • 1 Year Warranty

  • Fully Adjustable 12 dB/octave High and Low Pass Butterworth Crossovers

Specifications

Specification Details
Number of Channels 4
Total Power (Sum of Rated Power) 500 Watts
Rated Power (RMS Continuous Power) 75 W x 4 @ 4Ω
125 W x 4 @ 2Ω
250 W x 2 @ 4Ω Bridged/Mono
Dynamic Power (PVC/PowerCube™) 90 W x 4 @ 4Ω
160 W x 4 @ 2Ω
300 W x 2 @ 4Ω Bridged/Mono
Bridgeable Yes
Frequency Response 20 Hz - 20 kHz
Input Sensitivity Low-Level: 150 mV - 4 V
High-Level: 450 mV - 12 V
Circuit Topology Class Class-D
Total Harmonic Distortion (THD+N) < 1.0% (4Ω & 2Ω)
Signal Input Front Low-Level: 4 RCA
Front High-Level: 4-Pin Molex
Rear Low-Level: 4 RCA
Rear High-Level: 4-Pin Molex
Input Switch 2/4 Input (works for RCA/Hi-level inputs)
Signal Output Low-Level: 2 RCA (Pass-Thru active)
Tone Controls No
Crossover Controls Front High-Pass: 50-250 Hz @ 12 dB/oct Butterworth
Front Low-Pass: 50-250 Hz @ 12 dB/oct Butterworth
Rear High-Pass: 50-250 Hz @ 12 dB/oct Butterworth
Rear Low-Pass: 50-250 Hz @ 12 dB/oct Butterworth
All-Pass Yes
Remote Controls No
Visual Indicators Power/Protect, C.L.E.A.N. In, C.L.E.A.N. Out (Front & Rear)
Power Wire Gauge 4 AWG
Power Input Connector Compression Terminal Block
Speaker Wire Gauge 8 AWG
Speaker Output Connector Compression Terminal Block
Cooling Convection
Operating Voltage 9 - 16 VDC
Recommended Fuse (not included) 80 A
Max Current Draw (13.8V Sinewave) 59 A
Dimensions (H x W x D) 1.9" x 6.8" x 10.1" (4.9 cm x 17.3 cm x 25.5 cm)
Warranty 1 Year
