Rockford Fosgate R2-750X5 Prime 750 Watt 5-Channel Amplifier
Rockford Fosgate R2-750X5 Prime 750 Watt 5-Channel Amplifier
Couldn't load pickup availability
Share




Description
Rockford Fosgate R2-750X5 Prime 750 Watt 5-Channel Amplifier
Enhance your car audio system with the Rockford Fosgate R2-750X5, a 750-watt 5-channel amplifier designed for powerful performance. Engineered in Tempe, Arizona, this full-range Class-D amplifier operates efficiently at 4Ω or 2Ω stereo, with a mono subwoofer channel, delivering robust sound for speakers and subs, ideal for car audio enthusiasts.
Key Features of the Rockford Fosgate R2-750X5
- Class-D Technology: High-efficiency design reduces demand on the vehicle’s electrical system.
- C.L.E.A.N. Circuitry: Features clip lights for precise gain adjustment and optimal output.
- P.O.W.E.R. Supply: Increases dynamic power as voltage rises for enhanced performance.
- Punch EQ: Provides up to 3X bass boost to correct acoustic deficiencies.
- Balanced Differential Inputs: Includes RCA pass-through outputs for noise-free signal transfer.
- High-Level Input: Supports auto turn-on with hi/low level compatibility.
- CEA-2006 Compliant: Ensures accurate power ratings for reliable performance.
Specifications Table
Specification |
Details |
---|---|
Number of Channels |
5 |
Total Power (RMS) |
750 Watts |
Power Output (RMS) |
50W x 4 + 150W x 1 @ 4-Ohm |
Power Output (RMS) |
75W x 4 + 300W x 1 @ 2-Ohm |
Dynamic Power (PVC/PowerCube®) |
70W x 4 + 200W x 1 @ 4-Ohm |
Dynamic Power (PVC/PowerCube®) |
100W x 4 + 400W x 1 @ 2-Ohm |
Frequency Response |
20Hz - 20kHz (Front/Rear), 20Hz - 250Hz (Sub) |
Input Sensitivity |
150 mV - 4 V |
Circuit Topology |
Class-D (Full Range + Mono Sub) |
Efficiency |
>80% (typical at 2-Ohm) |
Total Harmonic Distortion (THD+Noise) |
<1.0% |
Dimensions |
1.9 x 6.8 x 12.5 inches (4.8 x 17.3 x 31.8 cm) |
Weight |
9.2 lbs (4.17 kg) |
Operating Voltage |
9 - 16 VDC |
Recommended Fuse |
80 A (not included) |
Average Current Draw |
45 A (13.8V Music) |
Max Current Draw |
90 A (13.8V Sinewave) |
Warranty |
1 Year (via authorized dealers) |
