Rockford Fosgate T1 Power Dual 2 ohm 12" Subwoofer
Rockford Fosgate T1 Power Dual 2 ohm 12" Subwoofer
Couldn't load pickup availability
Share







Description
Rockford Fosgate T1D212 Power 12-Inch T1 Dual 2-Ohm Subwoofer
Unleash thunderous bass with the Rockford Fosgate T1D212, a 12-inch Power Series subwoofer featuring dual 2-ohm voice coils and 800 watts RMS power handling. Engineered in Tempe, Arizona, this subwoofer delivers deep, impactful bass for vehicles With cutting-edge technologies like VAST and FlexFit, the T1D212 is designed for car audio enthusiasts seeking high-performance sound in custom installations.
Key Features of the Rockford Fosgate T1D212
- VAST Surround Technology: Increases cone area by up to 25%, enabling performance akin to a larger woofer.
- FlexFit Basket: Slot-mounted frame ensures precise mounting adjustments for versatile installations.
- Anodized Aluminum Voice Coil Former: Acts as a heat sink, dissipating heat up to 100°C for reliable high-SPL performance.
- SWIFT Terminal: Selectable Woofer Impedance Fused Termination simplifies impedance configuration (1 or 4 ohms) with fused protection.
- Kevlar Fiber Reinforced Paper Cone: Lightweight and durable for accurate, low-distortion bass.
- Symmetrical Dual Progressive Roll Spiders: Enhances stability during high excursion for consistent performance.
- Inductive Damping Heat Sink (IDHS): Reduces distortion and back EMF while improving thermal efficiency.
- CEA-2031 Compliant: Ensures accurate power handling for dependable operation.
- Klippel Verified: Optimized motor structure and voice coil alignment for maximum performance.
Specifications Table
Specification |
Details |
---|---|
Subwoofer Size |
12 inches |
Impedance |
Dual 2-Ohm (selectable 1 or 4 ohms via SWIFT) |
Power Handling (RMS) |
800 Watts |
Power Handling (Peak) |
1600 Watts |
Mounting Depth |
6.75 inches (171 mm) |
Cutout Diameter |
11.25 inches (285 mm) |
Sealed Box Volume |
1.25-2.25 cu. ft. (35.4-63.7 Liters) |
Vented Box Volume |
2.66 cu. ft. (75.3 Liters, tuning at 36 Hz) |
Sensitivity (1W/1m) |
85 dB |
Frequency Response |
28 Hz - 250 Hz |
Voice Coil Diameter |
3 inches (76 mm) |
Magnet Weight |
123 oz. (3.49 kg) |
Cone Material |
Kevlar Fiber Reinforced Paper |
Surround Material |
High Excursion TPE (Thermo-Plastic Elastomer) |
Basket Design |
Precision Cast and Vented Aluminum Alloy (FlexFit) |
Tinsel Leads |
Periodic-Stitched, Fatigue-Resistant |
Speaker Connector |
8 AWG Insulated All-Metal Compression Terminal |
Woofer Displacement |
0.099 cu. ft. (2.8 Liters) |
Compliance |
CEA-2031, Klippel Verified |
Additional Features |
Anodized Aluminum Dust Cap, Dual Spiders, IDHS Heat Sink, SWIFT Terminal |
Grille |
Included (Integral Trim Ring, T1SG-12 Compatible) |
Warranty |
1 Year (via authorized dealers) |
