LEFT AND RIGHT 2-CHANNEL INPUTS
Dynamo 400, 600X, 800X, 1100X, and 1600X subwoofers feature left and right input via RCA line level as well as speaker level connections.
LFE HOME THEATER INPUT
Dynamo 400 and 600X’s right inputs double as an LFE input for home theater applications. Dynamo 800X ups the ante by adding a discrete LFE RCA line level input. Dynamo 1100X and 1600X go one step further by adding both XLR and RCA inputs for LFE connection.
12V TRIGGER INPUT
Dynamo 800X, 1100X, and 1600X feature 12V Trigger Inputs, allowing an external device to turn the subwoofer on and off.
SIMULTANEOUS LFE AND 2-CHANNEL CONNECTIONS
Dynamo 800X, 1100X, and 1600X subwoofers features left and right input via robust connection and a control system that allows simultaneous connection of both 2-channel stereo music and multi-channel home theater and allows each source to have individual crossover and level settings, giving listeners a perfect performance in every application. LFE inputs use no low-pass filter, leaving crossover control to the processor. Left and right inputs integrate discrete user-adjustable low-pass filters allowing different level and crossover points when playing back two channel music.
Specifications
Specifications are subject to change without notice
Frequency Response | 24–200 Hz ±3 dB. Anechoic in LFE mode. |
Impedance | RCA: 8,300 Ohms Speaker Level: 2,000 Ohms (red to black) |
Low Frequency Transducer | 10” (25.4cm) high-excursion, inverted surround, polypropylene cone in a stamped steel basket with extended throw driver assembly; sealed non- resonant cabinet design. |
Amplifier | 300 Watts (600 peak) |
Software | Sub Control App: iOS and Android Anthem Room Correction: iOS, Android, and PC |
Room Correction | Anthem Room Correction (ARC) |
Controls (Backplate) | Level: Min–Max Setting Control: Local, App Power Mode: On, Trigger, Auto |
Controls (via Bluetooth) | Level: -40 to 12dB Low-Pass Filter (Frequency): 35–120Hz Low-Pass Filter (Order): Bypass, Third, Fourth Phase: 0–180° (1° Increments) Phase (Polarity): Normal, Inverted Preset Listening Modes: Music, Night, Movie 20–30Hz Level: ±10dB Anthem Room Correction (ARC): On, Off Tone Sweep (20–120Hz): On, Off, Pause (Frequency) |
Inputs (Audio) | Line Level: Left, Right, and LFE Speaker Level: Left and Right via banana jacks |
Inputs (Audio, Wireless) | SWT-X Receiver & Transmitter (sold separately) |
Inputs (Other) | USB: Micro USB (for ARC/Firmware Update) Trigger: 3.5mm, 5–24 DC |
Power Draw | Typical: 70W, Max: 360W, Idle: 10W, Standby: 0.5W |
Feet | Rubber, ETC (Energy Transfer Coupler) Spikes |
Weight | 30 lbs. (13.6 kg) |
Dimensions (HxWxD), Front-Firing | 14.6″ x 12.4″ x 12.7″ (37.1 cm x 31.5cm x 32.4cm) |
Dimensions (HxWxD), Down-Firing | 13.7″ x 12.4 ” x 13.1 ” (34.8 cm x 31.5cm x 33.3 cm) |
Finish | Satin Black |
